| 产品规格 | 软管内径 | 增强层外径 | 软管外径 | 最大工作压力 | 试验压力 | 最小爆破压力 | 最小弯曲半径 | 参考重量 | 适配接头 | |||||
| PN | DASH | IN | 最小mm | 最大mm | 最小mm | 最大mm | 最小mm | 最大mm | MPa | MPa | MPa | mm | kg/m | 定制 |
| LT788-16-1 | -10 | 5/8 | 15.5 | 16.7 | 25.8 | 27.4 | 28.2 | 29.8 | 1.0 | 2.0 | 4.0 | 105 | 0.98 | |
| LT788-19-1 | -12 | 3/4 | 18.8 | 19.8 | 31.2 | 32.8 | 34.2 | 35.8 | 1.0 | 2.0 | 4.0 | 130 | 1.14 | |
| LT788-25-1 | -16 | 1 | 24.8 | 25.8 | 37.8 | 40.2 | 42.8 | 45.2 | 1.0 | 2.0 | 4.0 | 150 | 1.50 | |
| LT788-32-1 | -20 | 1 1/4 | 31.6 | 32.6 | 45.8 | 48.2 | 48.8 | 51.5 | 1.0 | 2.0 | 4.0 | 190 | 1.80 | |
| LT788-38-1 | -24 | 1 1/2 | 37.7 | 38.8 | 53.2 | 56.2 | 57.5 | 60.5 | 1.0 | 2.0 | 4.0 | 240 | 2.10 | |
| LT788-45-1 | -28 | 1 3/4 | 44.6 | 45.6 | 59.9 | 62.9 | 62.5 | 65.5 | 1.0 | 2.0 | 4.0 | 260 | 2.30 | |
| LT788-51-1 | -32 | 2 | 50.7 | 52 | 66.7 | 69.7 | 69.5 | 72.5 | 1.0 | 2.0 | 4.0 | 300 | 2.75 | |
| LT788-64-1 | -40 | 2 1/2 | 63.7 | 65.3 | 80.5 | 83.5 | 83.5 | 86.5 | 0.8 | 1.6 | 3.2 | 800 | 3.50 | |
| LT788-76-1 | -48 | 3 | 75.5 | 77.3 | 96.0 | 100.0 | 100.0 | 104.0 | 0.8 | 1.6 | 3.2 | 920 | 4.50 | |
| LT788-89-1 | -56 | 3 1/2 | 88.5 | 90.5 | 109.0 | 113.0 | 113.0 | 117.0 | 0.8 | 1.6 | 3.2 | 1100 | 5.50 | |
| LT788-102-1 | -64 | 4 | 101.5 | 104 | 122.0 | 126.0 | 126.0 | 130.0 | 0.8 | 1.6 | 3.2 | 1300 | 6.50 | |
应用：适用于铁路、造船、建筑等行业对金属体表面进行风压喷砂除锈。
