| 产品规格 | 软管内径 | 软管外径 | 最大工作压力 | 试验压力 | 最小爆破压力 | 最小弯曲半径 | 参考重量 | 适配接头 | ||||
| PN | DASH | IN | 最小mm | 最大mm | 最小mm | 最大mm | MPa | MPa | MPa | mm | kg/m | 系列 |
| LT791-5-1 | -3 | 3/16 | 4 .5 | 5.1 | 9 .5 | 10 . 1 | 35 | 70 | 140 | 30 | 0 . 13 | BOPF/BTPF |
| LT791-6-1 | -4 | 1/4 | 6 .2 | 6 .8 | 12 .4 | 13 | 27 .5 | 55 | 110 | 40 | 0 . 15 | BOPF/BTPF |
| LT791-8-1 | -5 | 5/16 | 7 .6 | 8 .2 | 14 | 14 .6 | 25 | 50 | 100 | 55 | 0 .22 | BOPF/BTPF |
| LT791-10-1 | -6 | 3/8 | 9 .5 | 10 . 1 | 15 .6 | 16 .2 | 22 .5 | 45 | 63 .6 | 65 | 0 .24 | BOPF/BTPF |
| LT791-13-1 | -8 | 1/2 | 12 .4 | 13 | 19 .5 | 20 . 1 | 17 .5 | 35 | 70 | 85 | 0 .31 | BOPF/BTPF |
| LT791-16-1 | -10 | 5/8 | 15 .6 | 16 .2 | 23 | 23 .6 | 14 | 28 | 56 | 115 | 0 .41 | BOPF/BTPF |
| LT791-19-1 | -12 | 3/4 | 18 .7 | 19 .3 | 26 .2 | 27 .2 | 12 | 24 | 48 | 140 | 0 .50 | BOPF/BTPF |
| LT791-25-1 | -16 | 1 | 25 . 1 | 25 .7 | 33 .5 | 34 .5 | 10 | 20 | 40 | 180 | 0 .65 | BOPF/BTPF |
| LT791-6-2 | -4 | 1/4 | 6 .2 | 6 .8 | 13 | 13 .6 | 35 | 70 | 140 | 40 | 0 .29 | BOPF/BTPF |
| LT791-8-2 | -5 | 5/16 | 7 .6 | 8 .2 | 14 .6 | 15 .2 | 32 .5 | 65 | 130 | 50 | 0 .34 | BOPF/BTPF |
| LT791-10-2 | -6 | 3/8 | 9 .5 | 10 . 1 | 16 .4 | 17 | 29 | 58 | 116 | 70 | 0 .41 | BOPF/BTPF |
| LT791-13-2 | -8 | 1/2 | 12 .4 | 13 | 19 .5 | 20 . 1 | 26 | 52 | 104 | 80 | 0 .56 | BOPF/BTPF |
| LT791-16-2 | -10 | 5/8 | 15 .6 | 16 .2 | 23 | 23 .6 | 20 | 40 | 80 | 130 | 0 .63 | BOPF/BTPF |
| LT791-19-2 | -12 | 3/4 | 18 .7 | 19 .3 | 25 .5 | 26 .5 | 17 .5 | 35 | 70 | 160 | 0 .75 | BOPF/BTPF |
| LT791-25-2 | -16 | 1 | 25 . 1 | 25 .7 | 32 .5 | 33 .5 | 12 | 24 | 48 | 220 | 1 .0 | BOPF/BTPF |
应⽤：适⽤于油基和⽔基液压流体，⼴泛应⽤于⼯程机械、农林机械、船舶汽⻋等⾏业的液压传动、制动系统。
